DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 5-8 - Monitor Video Specification 5-43
5-8-2 Outputs
5-8-2-1 SVGA
5-8-2-2 TV Format
5-8-2-3 PAL BDGHI
5-8-2-4 NTSC EIA
Table 5-52 SVGA Specifidations
Standard Format Signal Sync DDC Termination
SVGA 800 x 600 / 75 Hz RGB: 0 - 700 mV
H: TTL
V: TTL
VESA DDC2
signals
75 ohms
Table 5-53 TV Fomat Specifidations
Type Standards Termination
SVHS
NTSC EIA and
PAL BDGHI
75 ohms
Composite
Video
NTSC EIA and
PAL BDGHI
75 ohms
RGB
NTSC EIA and
PAL BDGHI
75 ohms
B&W
NTSC EIA and
PAL BDGHI
75 ohms
General SVHS-luma SVHS-croma Composite RGB B&W
Line/field: 625/50
FH: 15625 Hz
FV: 50 Hz
Bandwidth: 6MHz
(luma)
Signal: 100 IRE
100% amplitude
Sync: 43 IRE
Burst amplitude:
+/- 21.5 IRE, 10
cycles
Fsc: 4.43361875
MHz 100%
saturation
Summed luma
and croma
Signal: 0-700
mV
Comp sync/H
sync/ V sync: 0.3
- 4 Vpp
SVHS luma
Table 5-54 PAL BDGH Specifidations
General SVHS-luma SVHS-croma Composite RGB B&W
Line/field: 525/60
FH: 15734 Hz
FV: 59.94 Hz
Bandwidth: Min.
4.2MHz (luma)
Signal: 92.5 IRE
(from black level)
100% amplitude
Blanking setup:
7.5 IRE
Sync: 40 IRE
Burst amplitude:
+/- 20 IRE, 9
cycles
Fsc: 3.579545
MHz 100%
saturation
Summed luma
and croma
Signal: 0-700
mV
Comp sync/H
sync/ V sync: 0.3
- 4 Vpp
SVHS luma
Table 5-55 NTSC EIA Specifidations
