DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 6-6 - Jumper and Dip Switch Setting 6-27
6-6-2 Jumper Setting
6-6-2-1 HDD (Parallel Type)
Always set the jumper between MASTER pins.
6-6-2-2 HDD (SATA Type)
Always set the jumper between “1.5Gb/s operation” pins.
Figure 6-106 HDD (Parallel Type) Jumper
Figure 6-107 HDD (SATA Type) Jumper
Master
1.5Gb/s operation
