MM2 Motor Manager 2 3-3
3 HARDWARE 3.2 KEYPAD
3
3.2 KEYPAD 3.2.1 SETPOINTS KEY
FUNCTION: The SETPOINT key allows the user to examine and alter all trip, alarm, and other MM2
setpoints. There are 6 pages of Setpoints:
• Page 1: Configuration
• Page 2: Protection
• Page 3: Process
• Page 4: Control
• Page 5: Monitoring
• Page 6: Factory Data
EFFECT: Pressing this key will cause the display to show the beginning of the next page of setpoints
data. If Actual Values data was on the display before pressing the SETPOINT key, setpoints page S1
will be shown:
USE: This key can be pressed at any time to view MM2 setpoints. To scroll through the setpoint
pages, press the SETPOINT key. To go from section to section within a page, press the MESSAGE
UP and MESSAGE DOWN keys. To go from line to line within a section, press the MESSAGE LEFT
and MESSAGE RIGHT keys.
To alter a setpoint, the VALUE UP and VALUE DOWN keys can be used. All setpoints can be incre-
mented or decremented to pre-determined limits. When the desired value is reached, the STORE
key must be used to save the new setpoint. If an altered setpoint is not stored, the previous value will
still be in effect. All control and protection features continue to operate while setpoints data is dis-
played.
3.2.2 ACTUAL VALUES KEY
FUNCTION: The ACTUAL key allows the user to examine all of the actual motor operating parame-
ters. There are 4 pages of ACTUAL VALUES data:
• Page 1: Data
• Page 2: Status
• Page 3: Inputs
• Page 4: Statistics
EFFECT: Pressing this key will cause the display to show the beginning of the next page of Actual
Values data. If setpoints data was on the display before pressing the ACTUAL key, page A1 of Actual
Values will be shown:
]] SETPOINTS
]] S1: CONFIGURATION
]] ACTUAL VALUES
]] A1: DATA
