MM2 Motor Manager 2 5-11
5 ACTUAL VALUES 5.5 A4 STATISTICS
5
5.5 A4 STATISTICS 5.5.1 DESCRIPTION
This page gives detailed information on the running time and accumulated number of various types
of trips. Actual Values Page 4 is divided into two sections, TIMERS and COUNTERS.
5.5.2 TIMERS
PATH: ACTUAL VALUES
tttt
A4 STATISTICS
t
TIMERS
5.5.3 COUNTERS
PATH: ACTUAL VALUES
tttt
A4 STATISTICS
tt
COUNTERS
RUNNING TIME =
2338 HOURS
The total accumulated time the motor has been running. Whenever
Contactor A and/or B is closed, the motor is considered to be running.
STOPPED TIME =
2 HOURS
This is the non-accumulated motor stopped time. This is the amount of
time that the motor has been stopped since the last time it was running.
This value will clear to zero the next time the motor is started.
INTERLOCK COUNTER =
34765 UNITS
This is the total number of switch closures read by the MM2 on a pro-
grammable input that has been configured to INTERLOCK COUNTER.
NUMBER OF STARTS =
26
This is the total number of contactor operations. When the MM2
receives feedback into either contactor status input to confirm that one
of the main contactors have closed, this counter will increment.
TOTAL TRIPS =
6
When the MM2 trips for any reason, this value is incremented. It is the
sum of all of the individual causes of trip.
OVERLOAD TRIPS =
1
When an overload trip occurs, this value is incremented.
THERMISTOR TRIPS =
2
When a thermistor trip occurs, this value is incremented.
GROUND FAULT TRIPS=
0
When a ground fault trip occurs, this value is incremented.
SINGLE PHASE TRIPS=
0
When a single phase trip occurs, this value is incremented.
ACCELERATION TRIPS=
0
When a single phase trip occurs, this value is incremented.
UNDERCURRENT TRIPS=
0
When an undercurrent trip occurs, this value is incremented.
UNDERPOWER TRIPS:
0
When an underpower trip occurs, this value is incremented.
STALLED ROTOR TRIPS
0
If a stalled rotor trip occurs, this value is incremented.
CONTROL COMMAND
TRIPS: 3
If a control trip occurs, this value is incremented (i.e. Plant Interlock,
Local Isolator etc.)
