6 COMMUNICATIONS 6.4 APPLICATIONS
6
6.4.4 USER DEFINABLE MEMORY MAP DEFAULT VALUES
For convenience default User Map values have been added. However, the User Definable Memory
Map is still fully customizable. The defaults are separated into three sections. Regular Polling data
items, data that is read when a Trip, Stop or Alarm occurs, and data that can be monitored as time
permits.
Table 6–11: MM2 MEMORY MAP USER DEFINABLE OUTPUTS (Sheet 1 of 2)
MODICON
REGULAR
ADDRESS
DESCRIPTION
REGISTER
VALUE
RANGE
STEP
VALUE
UNITS
AND
SCALE
FORMAT
USER MAP
DEFAULT
ADDRESS
(HEX)
DEC HEX
30021 20 0014 Gen Alarm Active Status Flags 1 F104 100
30022 21 0015 Gen Alarm Active Status Flags 2 F105 101
30023 22 0016 Interlock Alarm Active Status Flags F106 102
30027 26 001A Interlock Start Block Status Flags F106 103
30028 27 001B Trip Active Status Flags 1 F107 104
30029 28 001C Trip Active Status Flags 2 F108 105
30035 34 0022 Command Mode F6 106
30036 35 0023 Drive Status F7 107
30037 36 0024 Motor Mode F8 108
30049 48 0030 Phase Current Scale Factor F1 109
30050 49 0031 Phase A Current F1 10A
30051 50 0032 Phase B Current F1 10B
30052 51 0033 Phase C Current F1 10C
30053 52 0034 Ground Current F1 10D
30054 53 0035 Motor Load %FLC F1 10E
30055 54 0036 Thermal Capacity % F1 10F
30056 55 0037 Current Unbalance % F1 110
30017 16 0010 Switch Input Status F100 111
30020 19 0013 Operation Status Flags F103 112
30034 33 0021 Cause of Stop F5 113
30057 56 0038 Acceleration Time 0.1 x s F1 114
30058 57 0039 Last Starting Current F1 115
30059 58 003A O/L Time to Trip F1 116
30081 80 0050 Cause of Trip F9 117
30082 81 0051 Time to Reset min. F1 118
30083 82 0052 Pre Trip Phase A Current F1 119
30084 83 0053 Pre Trip Phase B Current F1 11A
Shading codes:
Regular Polling
Upon a Trip, Alarm, Stop
Monitor as time permits
