5-254 T35 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
INPUTS/OUTPUTS CHAPTER 5: SETTINGS
5
OUTPUT H1a OPERATE: “VO1
OUTPUT H1a RESET: “VO2
5.9.4 Virtual outputs
SETTINGS  INPUTS/OUTPUTS  VIRTUAL OUTPUTS VIRTUAL OUTPUT 1(96)
The virtual inputs and outputs are digital signals associated with UR-series internal logic signals. Virtual inputs include
signals generated by the local user interface. The virtual outputs are outputs of FlexLogic equations used to customize the
device. Virtual outputs can also serve as virtual inputs to FlexLogic equations.
There are 96 virtual outputs that can be assigned using FlexLogic. If not assigned, the output is forced to ‘OFF’ (Logic 0). An
ID also can be assigned to each virtual output. Virtual outputs are resolved in each pass through the evaluation of the
FlexLogic equations. Any change of state of a virtual output can be logged as an event if programmed to do so.
For example, if Virtual Output 1 is the trip signal from FlexLogic and the trip relay is used to signal events, the settings is
programmed as follows:
VIRTUAL OUTPUT 1 ID: "Trip"
VIRTUAL OUTPUT 1 EVENTS: "Disabled"
5.9.5 Resetting
5.9.5.1 Enhanced and standard front panels
SETTINGS  INPUTS/OUTPUTS  RESETTING
5.9.5.2 Graphical front panel
SETTINGS  INPUTS/OUTPUTS  RESETTING
Some events can be programmed to latch the front panel LED event indicators, target messages, and/or graphical front
panel annunciator windows. Once set, the latching mechanism holds the latched indicators, messages, or windows in the
set state after the initiating condition has cleared until a
RESET command is received to return these latches (not including
FlexLogic latches) to the reset state where the initiating condition has cleared. The
RESET command can be sent from the
front panel RESET button, a remote device via a communications channel, or any selected operand. The Modbus execute
function 05h with operation code 1 command is also available to perform the same function as the front panel RESET key.
RESET OPERAND — The three sources of RESET commands each activates the RESET OP FlexLogic operand. Each individual
source of a RESET command also activates its individual operand RESET OP (PUSHBUTTON), RESET OP (COMMS), or RESET OP (OPERAND) to
identify the source of the command. Each of these three operands generates an event in the event record when activated.
The
RESET OPERAND setting here selects the operand that activates the RESET OP (OPERAND) operand.
RESET ANNUNCIATOR — Used to select a FlexLogic operand that when activated acknowledges/resets all annunciator
windows on the graphical front panel. The other methods to acknowledge/reset annunciator windows include:
On the displayed page, press the RESET pushbutton with none of the annunciator windows selected to acknowledge/
reset all annunciator windows on that page
VIRTUAL OUTPUT 1
VIRTUAL OUTPUT 1 ID
Virt Op 1
Range: up to 20 alphanumeric characters
VIRTUAL OUTPUT 1
EVENTS: Disabled
Range: Disabled, Enabled
RESETTING
RESET OPERAND:
Off
Range: FlexLogic operand
RESETTING
RESET OPERAND:
Off
Range: FlexLogic operand
RESET ANNUNCIATOR:
Off
Range: FlexLogic operand
