6-26 T35 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
PRODUCT INFORMATION CHAPTER 6: ACTUAL VALUES
6
The order code, serial number, Ethernet MAC address, date and time of manufacture, and operating time are shown here.
The rear panel on the device contains similar information.
ETHERNET MAC ADDRESS — UR devices with firmware 7.0x and above have three Ethernet ports that can be used on three
networks. The MAC address displays for port 1. The MAC address for port 2 is one higher. The MAC address for port 3 is one
higher than port 2. In redundant mode, the MAC addresses for ports 2 and 3 are the same as port 2.
6.6.2 Firmware revisions
6.6.2.1 Enhanced and standard front panels
ACTUAL VALUES PRODUCT INFO FIRMWARE REVISIONS
The shown data is illustrative only. A modification file number of 0 indicates that, currently, no modifications have been
installed.
6.6.2.2 Graphical front panel
ACTUAL VALUES PRODUCT INFO FIRMWARE REVISIONS
ORDER CODE LINE 4: Range: up to 20 alphanumeric characters
SERIAL NUMBER: Range: standard GE serial number format
ETHERNET MAC ADDRESS
000000000000
Range: standard Ethernet MAC address format
MANUFACTURING DATE: Range: YYYY/MM/DD HH:MM:SS
OPERATING TIME:
0:00:00
Range: operating time in HH:MM:SS
CT/ VT ADVANCED DIAG
ACTIVE: No
Range: Yes, No
LAST SETTING CHANGE:
1970/01/01 23:11:19
Range: YYYY/MM/DD HH:MM:SS
FIRMWARE REVISIONS
T35 Relay
REVISION: 7.6x
Range: 0.00 to 655.35
Revision number of the application firmware.
MODIFICATION FILE
NUMBER: 0
Range: 0 to 65535 (ID of the MOD FILE)
Value is 0 for each standard firmware release.
BOOT PROGRAM
REVISION: 7.01
Range: 0.00 to 655.35
Revision number of the boot program firmware.
FRONT PANEL PROGRAM
REVISION: 2.01
Range: 0.00 to 655.35
Revision number of front panel program firmware.
COMPILE DATE:
2016/09/15 04:55:16
Range: YYYY/MM/DD HH:MM:SS
Date and time when product firmware was built.
BOOT DATE:
2013/09/15 16:41:32
Range: YYYY/MM/DD HH:MM:SS
Date and time when the boot program was built.
FPGA PROGRAM
REVISION: 02.02
Range: 0.00 to 655.35
Revision number for FPGA.
FPGA DATE:
2016/09/15 16:41:32
Range: YYYY/MM/DD HH:MM:SS
Date and time when the FPGA was built.
FIRMWARE REVISIONS
T35 Relay
REVISION: 7.6x
Range: 0.00 to 655.35
Revision number of the application firmware.
