GE T35 User Manual

6-22 T35 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
RECORDS CHAPTER 6: ACTUAL VALUES
6
6.4.8 Transducer inputs/outputs
ACTUAL VALUES  METERING  TRANSDUCER I/O DCMA INPUTS  DCMA INPUT xx
Actual values for each DCmA input channel that is enabled are displayed with the top line as the programmed channel ID
and the bottom line as the value followed by the programmed units.
ACTUAL VALUES  METERING  TRANSDUCER I/O RTD INPUTS  RTD INPUT xx
Actual values for each RTD input channel that is enabled are displayed with the top line as the programmed channel ID
and the bottom line as the value.
6.5 Records
6.5.1 User-programmable fault reports
ACTUAL VALUES  RECORDS  USER-PROGRAMMABLE FAULT REPORTS
This menu displays the user-programmable fault report actual values. See the User-Programmable Fault Report section in
chapter 5 for information on this feature.
6.5.2 Event records
6.5.2.1 Enhanced and standard front panels
ACTUAL VALUES  RECORDS  EVENT RECORDS
The event records menu shows the contextual data associated with up to the last 1024 events, listed in chronological
order from most recent to oldest. When all 1024 event records have been filled, the oldest record is removed as a new
record is added. Each event record shows the event identifier/sequence number, cause, and date/time stamp associated
with the event trigger. See the
COMMANDS  CLEAR RECORDS menu for clearing event records.
 DCMA INPUT xx


DCMA INPUT xx
0.000 mA
 RTD INPUT xx


RTD INPUT xx
-50 °C
 USER-PROGRAMMABLE
 FAULT REPORTS

NEWEST RECORD
NUMBER: 0

LAST CLEARED DATE:
2002/8/11 14:23:57

LAST REPORT DATE:
2002/10/09 08:25:27
 EVENT RECORDS


EVENT: XXX
XXX

Date and time stamps

EVENT: 3
POWER ON

EVENT 3
DATE: 2000/07/14

EVENT: 2
POWER OFF

EVENT 3
TIME: 14:53:00.03405

EVENT: 1
EVENTS CLEARED
