CHAPTER 6: ACTUAL VALUES PRODUCT INFORMATION
T35 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL 6-25
6
6.5.5 Breaker maintenance
ACTUAL VALUES  RECORDS  MAINTENANCE  BREAKER 1(6)
There is an identical menu for each of the breakers.
The
BKR 1 ACC ARCING AMP values are in units of kA
2
-cycles. See the COMMANDS  CLEAR RECORDS menu for clearing
breaker arcing current records.
The
BREAKER OPERATING TIME is defined as the slowest operating time of breaker poles that were initiated to open.
All of the values are stored in non-volatile memory and retained with power cycling.
6.6 Product information
6.6.1 Model information
ACTUAL VALUES  PRODUCT INFO  MODEL INFORMATION
 BREAKER 1


BKR 1 ACC ARCING AMP
φA: 0.00 kA2-cyc

BKR 1 ACC ARCING AMP
φB: 0.00 kA2-cyc

BKR 1 ACC ARCING AMP
φC: 0.00 kA2-cyc

BKR 1 OPERATING TIME
φA: 0 ms

BKR 1 OPERATING TIME
φB: 0 ms

BKR 1 OPERATING TIME
φC: 0 ms

BKR 1 OPERATING
TIME: 0 ms

BKR 1 ARCING AMP φA:
0.00 kA2-cyc

BKR 1 ARCING AMP φB:
0.00 kA2-cyc

BKR 1 ARCING AMP φC:
0.00 kA2-cyc

BKR 1 AMP MAX φA:
0.00 kA

BKR 1 AMP MAX φB:
0.00 kA

BKR 1 AMP MAX φC:
0.00 kA
 MODEL INFORMATION


ORDER CODE LINE 1:
T35-A00-AAA-A0A-A0A-
Range: standard GE order code format

ORDER CODE LINE 2:
A0A-A0A-A0A
Range: up to 20 alphanumeric characters

ORDER CODE LINE 3: Range: up to 20 alphanumeric characters
