CHAPTER 6: ACTUAL VALUES STATUS
T35 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL 6-7
6
The present status of the eight digital counters displays here. The status of each counter, with the user-defined counter
name, includes the accumulated and frozen counts (the count units label also appears). Also included, is the date and time
stamp for the frozen count. The
COUNTER 1 MICROS value refers to the microsecond portion of the time stamp.
6.3.11 Selector switches
ACTUAL VALUES  STATUS  SELECTOR SWITCHES
The display shows both the current position and the full range. The current position only (an integer from 0 through 7) is the
actual value.
6.3.12 Flex States
ACTUAL VALUES  STATUS  FLEX STATES
There are 256 FlexState
TM
bits available. The second line value indicates the state of the given FlexState bit.
6.3.13 Ethernet
ACTUAL VALUES  STATUS  ETHERNET
These values indicate the status of the first, second, and third Ethernet links.
6.3.14 Real time clock synchronizing
ACTUAL VALUES  STATUS  REAL TIME CLOCK SYNCHRONIZING

Counter 1 FROZEN:
1970/01/01 00:00:00
Range: YYYY/MM/DD HH:MM:SS

Counter 1 MICROS:
0
Range: 0 to 4294967295 in steps of 1
 SELECTOR SWITCHES


SELECTOR SWITCH 1
POSITION: 0/7
Range: Current Position / 7

SELECTOR SWITCH 2
POSITION: 0/7
Range: Current Position / 7
 FLEX STATES


PARAM 1: Off
Off
Range: On, Off


PARAM 256: Off
Off
Range: On, Off
 ETHERNET


ETHERNET PRI LINK
STATUS: Fail
Range: Fail, OK

ETHERNET SEC LINK
STATUS: Fail
Range: Fail, OK

ETHERNET TER LINK
STATUS: Fail
Range: Fail, OK
 REAL TIME CLOCK
 SYNCHRONIZING

RTC SYNC SOURCE:
None
Range: see below

GRANDMASTER ID:
0X0000000000000000
Range: any 8 octet value
