T35 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL A-1
T35 Transformer Protection System
Appendix A: FlexAnalog operands
Appendices
FlexAnalog operands
This appendix outlines FlexAnalog parameters.
A.1 FlexAnalog items
A FlexAnalog parameter is an analog parameter.
FlexAnalog items are also viewable in a web browser. Enter the IP address of the UR, access the Device Information Menu
option, then the FlexAnalog Parameter Listing option. Entries displayed online depend on order code.
Table A-1: FlexAnalog data items
Address FlexAnalog name Units Description
5792 RGF 1 Igd Mag Amps Restricted ground fault 1 differential ground current magnitude
5794 RGF 1 Igr Mag Amps Restricted ground fault 1 restricted ground current magnitude
5796 RGF 2 Igd Mag Amps Restricted ground fault 2 differential ground current magnitude
5798 RGF 2 Igr Mag Amps Restricted ground fault 2 restricted ground current magnitude
5800 RGF 3 Igd Mag Amps Restricted ground fault 3 differential ground current magnitude
5802 RGF 3 Igr Mag Amps Restricted ground fault 3 restricted ground current magnitude
5804 RGF 4 Igd Mag Amps Restricted ground fault 4 differential ground current magnitude
5806 RGF 4 Igr Mag Amps Restricted ground fault 4 restricted ground current magnitude
5808 RGF 5 Igd Mag Amps Restricted ground fault 5 differential ground current magnitude
5810 RGF 5 Igr Mag Amps Restricted ground fault 5 restricted ground current magnitude
5812 RGF 6 Igd Mag Amps Restricted ground fault 6 differential ground current magnitude
5814 RGF 6 Igr Mag Amps Restricted ground fault 6 restricted ground current magnitude
5824 Field RTD 1 Value --- Field RTD 1 value
5825 Field RTD 2 Value --- Field RTD 2 value
5826 Field RTD 3 Value --- Field RTD 3 value
5827 Field RTD 4 Value --- Field RTD 4 value
5828 Field RTD 5 Value --- Field RTD 5 value
5829 Field RTD 6 Value --- Field RTD 6 value
5830 Field RTD 7 Value --- Field RTD 7 value
5831 Field RTD 8 Value --- Field RTD 8 value
5832 Field TDR 1 Value --- Field TDR 1 value
