CHAPTER 6: ACTUAL VALUES METERING

T35 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL 6-17

The daily rate loss of life is summarized at 00:00 h, and displayed for the next 24 hour period. The transformer

accumulated loss of life in hours is also available. It can be reset by either changing the

XFMR INITIAL LOSS OF LIFE setting or

through the COMMANDS  CLEAR RECORDS  CLEAR LOSS OF LIFE RECORDS command.

6.4.3 Sources

6.4.3.1 Menu

ACTUAL VALUES  METERING  SOURCE SRC 1

This menu displays the metered values available for each source.

Metered values presented for each source depend on the phase and auxiliary VTs and phase and ground CTs assignments

for this particular source. For example, if no phase VT is assigned to this source, then any voltage, energy, and power

values are unavailable.

6.4.3.2 Phase current metering

ACTUAL VALUES  METERING  SOURCE SRC 1  PHASE CURRENT

 SOURCE SRC 1





 PHASE CURRENT

 SRC 1

See below



 GROUND CURRENT

 SRC 1

See page 6-18



 PHASE VOLTAGE

 SRC 1

See page 6-18



 AUXILIARY VOLTAGE

 SRC 1

See page 6-19



 POWER

 SRC 1

See page 6-19



 FREQUENCY

 SRC 1

See page 6-20

 PHASE CURRENT

 SRC 1



SRC 1 RMS Ia: 0.000

b: 0.000 c: 0.000 A



SRC 1 RMS Ia:

0.000 A



SRC 1 RMS Ib:

0.000 A



SRC 1 RMS Ic:

0.000 A



SRC 1 RMS In:

0.000 A



SRC 1 PHASOR Ia:

0.000 A 0.0°



SRC 1 PHASOR Ib:

0.000 A 0.0°



SRC 1 PHASOR Ic:

0.000 A 0.0°



SRC 1 PHASOR In:

0.000 A 0.0°



SRC 1 ZERO SEQ I0:

0.000 A 0.0°
