GE T35 User Manual

6-6 T35 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
STATUS CHAPTER 6: ACTUAL VALUES
6
6.3.8 RxGOOSE status
ACTUAL VALUES  STATUS  RxGOOSE STATUS
The
All RxGOOSE Online actual value does not consider RxGOOSE that are not configured or are not used by any RxGOOSE
Input.
6.3.9 RxGOOSE statistics
ACTUAL VALUES  STATUS  RxGOOSE STATISTICS  RxGOOSE 1(64)
stNum — State number. The most recently received value in GOOSE message field stNum. The publisher increments stNum
each time that the state of one or more of the GOOSE message members is sent with a revised value.
sqNum — Sequence number. The most recently received value in GOOSE message field sqNum. The publisher sets sqNum
to zero each time the state of one or more of the GOOSE message members is sent with a new value, and it increments it
whenever a GOOSE message is resent without any member value change.
IGMP — Multicast (SSM and ASM) modes of R-GOOSE reception require that the T35 device subscribe to a multicast group
over the Internet Group Management Protocol (IGMP) enabled network. R-RxGOOSE## IGMP status On indicates that IGMP
negotiation with a network device (for example a router) was successful. In the case where setting R-RxGOOSE1 DST IP is
configured to a multicast address and this status indicates Off, R-GOOSE reception cannot be successful, and therefore
communication network diagnosis needs to be carried out. This status is relevant to R-GOOSE reception when configured
for SSM or ASM reception modes. It is not relevant for GOOSE or for R-GOOSE in unicast reception mode.
6.3.10 Digital counters
ACTUAL VALUES  STATUS  DIGITAL COUNTERS  DIGITAL COUNTERS Counter 1(8)
 RxGOOSE
 STATUS

All RxGOOSE Online:
Yes
Range: Yes, No

RxGOOSE 1 Status:
Offline
Range: Online, Offline


RxGOOSE 64 Status:
Offline
Range: Online, Offline
The T35 is provided with optional IEC 61850 capability. This feature is specified as a software option at the time
of ordering. See the Order Codes section of chapter 2 for details.
 RxGOOSE 1


RxGOOSE 1
stNum: 0
Range: 0 up to 4,294,967,295

RxGOOSE 1
sqNum: 0
Range: 0 up to 4,294,967,295

R-RxGOOSE 1
IGMP: Off
Range: On, Off
The T35 is provided with optional IEC 61850 capability. This feature is specified as a software option at the time
of ordering. See the Order Codes section of chapter 2 for details.
 DIGITAL COUNTERS
 Counter 1

Counter 1 ACCUM:
0

Counter 1 FROZEN:
0
