GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 3 - Setup Instructions 3-41
3-7-4 Adjustment of Printer Settings
1.) After system restart, press the UTILITIES key on the control panel.
2.) In the “Utilities” menu touch SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) On the left side of the screen select CONNECTIVITY
and then click on the PERIPHERALS tab.
4.) Select the desired printer from the Printer Settings pull-down menu and click the EDIT
button.
5.) Confirm the warning message with the YES
button. The “Printer Properties” appear.
To adjust the UP-D897 B&W Printer see: Section 3-7-4-1 "UP-D897 Printer - Settings".
To adjust the P95D B&W Printer see: Section 3-7-4-2 "P95D Printer - Settings".
To adjust the CP30D Color Printer see: Section 3-7-4-3 "CP30D Printer - Settings".
To adjust the UP-D25MD Color Printer see: Section 3-7-4-4 "UP-D25MD Printer - Settings".
To adjust the UP-D23MD Color Printer see: Section 3-7-4-5 "UP-D23MD Printer - Settings"
Figure 3-40 Select the desired printer
!! WARNING:
After each printer installation, the leakage currents have to be measured
acc. IEC 60601-1 resp. UL 60601-1.
select the desired printer
from the pull-down menu
