GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 4 - Functional Checks 4-37
4-5-3 Save Full System Configuration (Full Backup)
A backup of the Full System Configuration always contains the following data
• User Settings (databases and files containing User Programs, 2D/3D/4D Programs, Auto Text
entries, gray curves and complete System settings such as language, time/date format, etc.)
• Measure Configuration (user specific measure setup settings)
• Patient Archive (database containing patient demographic data and measurements) - no images
• Options (Permanent Key that is specific for enabled software options and Demo Key)
• Image Transfer Configuration (DICOM settings e.g., DICOM servers, AE Title, Station Name, etc.)
• Network Configuration (network settings including the computer name)
• Service Platform (state of the Service Software)
NOTE: It is recommended to “Full Backup” system configuration data before upgrading the software and/or
image settings (presets). This ensures that if settings need to be reloaded, will be the same ones the
customer was using prior to service.
1.) Press the UTILITIES
key on the control panel.
2.) In the “Utilities” menu touch SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) On the left side of the screen select BACKUP
and then click the SYSTEM CONFIGURATION tab.
4.) Click the SAVE
button of the “Full System Configuration” group.
5.) Choose the Destination.
6.) Enter the description of the full backup.
7.) Select the NEXT
button.
8.) To start the backup process click YES
.
After copying the data, the Voluson E8 / Voluson E6 reboots and the application starts again.
Figure 4-27 System Configuration Save
!! CAUTION:
Image data will not be backed up!
To backup the Image Archive, refer to Section 4-5-6 on page 4-42.
choose destination
enter description
click [Next] button
