GE Voluson E8 Service Manual

GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
9-10 Section 9-5 - User Interface
NOTE: The installed Console version is shown in the System Info page (see: Figure 7-1 on page 7-3).
Table 9-6 User Interface (cont’d)
Item Part Name Part Number Description Qty CRU FRU
230
Console Alphanumeric board 2 (R)
KTZ280064
Alphanumeric Keyboard - English,
(check if special key cap kit is needed;
see: Table 9-12 on page 9-18)
1N Y
231
Console Alphanumeric board 3 (R)
KTZ302739
Alphanumeric Keyboard - English,
(check if special key cap kit is needed;
see: Table 9-12 on page 9-18)
1N Y
232
Console Interface Board 2
KTZ280065 Console Interface Board 1 N Y
233
Console Main Board left A/N (W)
KTZ280232
Console Main Board left incl. alphanumeric keyboard -
English, (check if special key cap kit is needed;
see: Table 9-12 on page 9-18)
1 N Y
234
Console Main Board right (W)
KTZ280234 Console Main Board right 1 N Y
235
A/N Keyboard (W)
KTZ280233 Alphanumeric Keyboard - English 1 N Y
236
Console Touchscreen (W)
KTZ280235 Console Touchscreen Display 1 N Y
237
TGC-Slide potentiometers (R)
KTZ220874
TGC-Slide potentiometers
Note:
2 versions are available that are fully compatible.
1N Y
238
TGC-Slide potentiometers (W)
KTZ280228 TGC-Slide potentiometers 1 N Y
239
Trackball Ring (R)
KTZ220868 Trackball fixation ring 1 Y Y
240
Trackball Ring (W)
KTZ280230 Trackball fixation ring 1 Y Y
241
Trackball Kit 2 (R) - optical
KTZ280063
laser sampling Trackball Kit , generates
X/Y-coordinates of trackball-movements like a PC-Mouse
1 N Y
242
Trackball Kit (R) - mechanical
KTZ220867
mechanical sampling Trackball Kit , generates
X/Y-coordinates of trackball-movements like a PC-Mouse
1N Y
243
Trackball Kit (W)
KTZ280229
mechanical sampling Trackball Kit, generates X/Y-
coordinates of trackball-movements like a PC-Mouse
1N Y
