3 - Description
14
View
Identification plates
An identification plate fitted on the frame indicates producer name,
model and serial number.
Frame, boom center frame and other main steel components have
identification plates indicating type and part number. (not illustrated)
Roadworthiness
When driving on public roads and other areas where the highway code applies, or areas with special rules and regulations
for marking and lights on implements, you should observe these and equip implements accordingly.
ATTENTION! Max. driving speed for models without brakes and for models equipped with brakes is different. Be aware
that these speeds may differ due to local law. Contact local authorities for information of max. driving speeds!
23. Distribution valves (not illustrated)
24. Rinsing tank
25. Main tank
26. ChemLocker (with optional FoamMarker tank)
27. Spray wand for External Cleaning Device
28. CycloneFilter
23
24 25
26 27 28
