Hardi NAVIGATOR 4000 Original Instruction Book

8 - Technical specifications
102
Weight
3000 litre:
4000 litre:
Wheel and axle dimensions
Boom width Axle load* Drawbar load* Total weight* Axle load** Drawbar load** Total weight**
12 m 2720 120 2840 5420 920 6340
15 m 2745 139 2884 5445 939 6384
16 m 2750 150 2900 5450 950 6400
18 m 2810 170 2980 5510 970 6480
*Weights with empty tank
**Weights with full tank
All weights in Kilograms (kg)
Boom width Axle load* Drawbar load* Total weight* Axle load** Drawbar load** Total weight**
12 m 2735 130 2865 6340 1025 7365
15 m 2760 149 2909 6365 1044 7409
16 m 2765 160 2925 6370 1055 7425
18 m 2825 180 4620 6430 1075 7505
*Weights with empty tank
**Weights with full tank
All weights in Kilograms (kg)
Wheel Fixed axle Short axle Long axle Mudguards Clearance*
11.2x48” 1800 or 2000 mm 1500-2000 mm 1800-2250 mm 345 mm 700 mm
12.4x46” 1800 or 2000 mm 1520-2000 mm 1800-2250 mm 345 mm 705 mm
12.4x52” 1800 or 2000 mm 1520-2000 mm 1800-2250 mm N/A 790 mm
13.6x48” 1800 or 2000 mm 1540-2000 mm 1800-2250 mm 345 mm 735 mm
16.9x38” 1800 or 2000 mm 1630-2000 mm 1800-2250 mm 590 mm 680 mm
18.4x38” 1800 or 2000 mm N/A 1800-2250 mm 590 mm 675 mm
20.8x38” 1800 or 2000 mm N/A 1800-2250 mm 590 mm 695 mm
*under axle
