Hardi NAVIGATOR 4000 Original Instruction Book

4 - Sprayer setup
39
Hydraulic systems
General info
Ensure that the snap couplers are clean before connection!
After having operated the boom and the system has been filled with oil, check the tractor’s hydraulic oil level and top up, if
necessary.
€
DANGER! Test of the hydraulic system should be done very cautiously. There may be air trapped in the system which
can cause violent movements of the boom.
€
DANGER! Hydraulic leaks: Never use your fingers to locate a leakage in any part of the hydraulic system. Due to high
pressure, hydraulic oil may penetrate the skin.
Requirements - tractor
The hydraulic system requires:
VHY model
• One single-acting outlet to raise and lower the boom.
• One double-acting outlet to fold and unfold the boom.
• One double-acting outlet for hydraulic slanting control (VHY option).
VHZ model
• One double-acting outlet for the electro-hydraulic operation of the boom functions.
The hydraulic hoses are marked with arrows to indicate the direction of oil flow.
The hydraulic system requires an oil flow between 25 and 130 l/min (5.5 - 28.6 Imp. gal/min.) and a min. pressure of 170 bar
(2500 p.s.i.).
