If Yes is selected:
Freeze Protect Temperature? Select the temperature to be used for
freeze protection. Temperature is adjustable from 33ºF-42ºF (1ºC-
6ºC). 38ºF (3ºC) is default. This threshold will be used for all outputs
that have freeze protection enabled.
Freeze Protect Speed? This is the speed of the pump while freeze
protection is active. Select the desired pump speed %.
How many Heaters? This question is for THIS BODY OF WATER ONLY. For example: If you have 2
heaters, one for the pool Body of Water and one for the spa Body of Water, you would answer “1” to
this question. Note that you can have a maximum of 5 heaters/chillers per Body of Water.
If “1”or more is selected:
Heater Cooldown Enabled? This feature ensures that the heater cools down before wa-
ter circulation is stopped. When enabled, the OmniPL will continue to run the filter pump
for 5 minutes after the heater turns off.
Heater Extend Enabled? If “Enabled”, the filter extend logic keeps the filter pump run-
ning beyond the normal turn-off time until the pool (or spa) is heated up to the desired
temperature setting. Heater extend will NOT cause the filter pump to turn on, it will only
delay the turn off time when the heater is operating.
Settable Water Temperature Range? This is the maximum and minimum allowed set-
tings for heating and/or cooling.
Select and Configure a Heater At this screen, you can add, delete and configure your
heater(s). Select the desired heater, then touch the Advance button. When finished con-
figuring heater(s), you’ll be returned to this same screen. Touch the Done button and
advance to the next section of configuration. Refer to the following information when
configuring heater(s):
Do you want to configure a Smart Heater? This option only appears if you have a
heater with OmniPL remote control capability connected to your OmniPL and powered
on. Select “Yes” if you would like to configure this heater now or “No” if you would like to
configure a different heater.
If Yes is selected:
Which Hayward Unique Address? Select the HUA of the Smart Heater that
you would like to configure.
Name Heater Select the box, then type the desired name for your heater. This
name will be used when referring to this particular heater.
Does Heater Have a Valve? Select whether or not the heater has an associ-
ated valve that will turn on when the heater is activated. If Yes is selected, the
following screen will ask where the valve is wired (refer to Connection Table for
this information).
35
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
