Where is the Valve(s) Wired? Selecting the box will bring you to a table show-
ing all detected low voltage relays. Select the relay(s) that is wired to the water
feature valve(s), then advance. The valve(s) should now be shown in the box.
Advance to the next screen to continue water feature configuration.
Freeze Protection Enabled? Freeze protection is used to protect the pool and plumbed
equipment against freeze damage during cold temperatures. If freeze protection is en-
abled AND the air temperature falls below the freeze threshold (refer to pump configura-
tion), the OmniPL will turn on the water feature pump to circulate the water.
Would You Like To Configure A Default Startup Speed For Water Feature? If the
water feature has a valve and the system uses a VSP filter pump, the OmniPL allows you
to set a startup pump speed for the water feature, regardless of the pump’s schedule. The
speed will change at the next scheduled interval.
Do You Want to Configure Any Lights? Select yes if you are using any type of pool or spa lights.
The options are Universal ColorLogic (UCL), ColorLogic 4.0 (CL4.0), ColorLogic 2.5 (CL2.5), Water-
Bowl, Pentair Color LED (P-COLOR), Jandy Color LED (Z-Color), Incandescent, and Other. Transform-
ers powering Universal ColorLogic lights must all be connected to the same high voltage relay for
synchronization to function properly. If using Omni Direct mode, you must use an internal relay, not
an HLRELAYBANK.
If Yes is selected:
What Kind of Lights? Touch the box to select the type of lights that will be used. The
options are UCL (14V), CL4.0 (120V), CL2.5 (14V), WaterBowl, P-Color, Z-Color, Incan-
descent, and Other.
Name the Group of Lights - Touch the box and use the keyboard to name the lights.
How Many Relays are Lights Wired to? Select the number of relays used by the lights.
Which Relay is it Wired to? Touching the box(es) will bring you to a table showing all
detected relays. Select the relay(s) that are connected to the lights and touch the Done
button. If the lights are connected to a Smart Power Transformer, select the zone(s) that
the lights are wired to. The relay(s) should now be shown in the box(es) and you can ad-
vance to the next screen to continue the configuration.
If UCL was previously selected:
Would you like to test for Omni Direct capability? For UCL lights manufac-
tured after June 2018, you can select Yes and the OmniPL will test your lights
to confirm. If your lights blink white after the test, you can enable Omni Direct
mode. If not, the UCL light will default to UCL Standalone mode. Note that if you
are configuring a WaterBowl light, the Flicker feature will only be available if the
light is set to OmniDirect mode.
How Many Accessories? Select the number of accessories that will be used for this Body of Water
only. You’ll have an opportunity to configure accessories for the spa and also the backyard at a later
point.
45
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
