Before you Begin
What’s Included
Check that the following components have been included in your package:
• OmniPL Wiring Panel
• OmniPL Controller
• 2 Temperature Sensors
What’s NOT Included
Some of the additional items that you may need to complete an installation include:
Wire
• Wire/conduit for incoming power and high voltage connections
• Wire for remote variable speed pump control and other low voltage devices
• Ethernet cable (if not using wifi)
Miscellaneous
• Valve actuator to automate pool functions
• Flow switch (included with some models) for optional pump protection/flow monitoring (re-
quired if using chlorination or Sense and Dispense accessories)
• Mounting hardware for mounting Wiring Panel and Controller
• Cable/cord connectors to provide knockout strain relief
• Wire nut connectors
Tools Needed
Phillips and flat screwdrivers Wire cutters and strippers Knife to cut conduit
Drill and drill bits (including 3/8”) Pliers Level
Accessory Products - Order Separately
GLX-FLO Flow Switch used to detect water flow
GVA-24 Valve Actuator
PC Temperature Sensor for 3rd input
HLSPASIDE Wired Spa Remote
HLRELAY Single High Voltage relay kit
HLH485RELAY Single RS485 Smart Relay kit
HLWALLMOUNT Wired Wall Mount Remote Terminal
HLWIRELESS Portable Wireless Remote Terminal
HL-CHEM ORP & pH Sensing Kit for monitoring and controlling pool chemistry (requires
GLX-FLO flow switch)
HL-CHEM4-ACID Liquid acid feeder (requires GLX-FLO flow switch)
HL-CHEM4-CHLOR Liquid chlorine feeder (requires GLX-FLO flow switch)
TCELLS325 Chlorinator Cell - generates chlorine for pools up to 25k gallons
TCELLS340 Chlorinator Cell - generates chlorine for pools up to 40k gallons
TCELLS315 Chlorinator Cell - generates chlorine for pools up to 15k gallons
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
2
