189
10.1.2 Docking station
Dimensions 206 × 135 × 61 mm (8.10 × 5.30 × 2.40 inches)
Weight 566 g (1.24 pounds)
Network communication
speed:
PDS
+
: 100Mbps
PDS: 10Mbps
System operating temperature See relevant Instructions for Use
Docking station storage and
transport temperature
0 - 50 °C (32 - 122 °F)
Docking station operating and
storage humidity
< 90% RH (non-condensing)
Pollution degree 2
Overvoltage category II
Altitude up to 2000 m above sea level
Power Adapter/Input FW7556M/06: 100-240V~/50–60 Hz/400-200 mA
FW8001/06: 100-240V~/ 50–60 Hz/400-200 mA
Power Adapter/Output FW7556M/06: 6 V /2500 mA
FW8001/06: 5.9 V /3000 mA
10.2 EMC and Electrical Safety
The System is tested and complies with IEC 61010-1, IEC/EN 61010-2-101 and IEC/EN
61326-2-6 (including applicable parts of IEC/EN 61326-1).
The System has been tested for indoor use.
When using the Analyzer standalone or together with one Primary Docking Station it has
been designed and tested to CISPR 11 Class B.
When using the Analyzer with a standalone Secondary Docking Station or one or several
Secondary Docking Stations connected to a Primary Docking Station it has been designed
and tested to CISPR 11 Class A. In a domestic environment it may cause radio interference,
in which case, you may need to take measures to mitigate the interference.
