HemoCue 201 DM Reference Manual

27
2.3 Display buttons and symbols
2.3.1 Navigation buttons
Button Designation Function
Erase button Erases the last input.
Previous image
button
Returns to the previous image
Note that Inputs/changes made in the
current image will not be saved.
ABC
ABC
Text mode button Switches to text input mode.
123
123
Numeric mode
button
Switches to the numeric input mode.
Barcode Scanner
button
Activates the Barcode Scanner.
Scroll bar arrow
(Up)
Scrolls upwards in a list of dierent
options or in a text.
Scroll bar arrow
(Down)
Scrolls downwards in a list of dierent
options or in a text.
Next image button Continues to the next image in the Help
sequence.
