HemoCue 201 DM Reference Manual

41
3.2.1 Liquid Controls
A Liquid Control is a liquid with a known
concentration, intended for checking the
accuracy of the System.
Results from Liquid Controls can only be
stored as QC measurements if the Liquid
Control specifications have been entered.
FIGURE 3-6
When the Liquid Controls button is pressed in
the Define Lists menu (see FIGURE 3-5), the
Liquid Controls list(1) is displayed (see
FIGURE 3-6). The Liquid Controls list can hold
up to twelve dierent Liquid Control
specifications.
When pressing the Add button(2) to add a
new Liquid Control specification, the
following Liquid Controls options(1) are
displayed:
• Level 1
• Level 2
• Level 3
• Level 4
• Level 5
FIGURE 3-7
Level 1, Level 2, Level 3, Level 4 and Level 5
refer to the dierent concentration levels of
Liquid Controls. The settings procedure is
the same for all concentration levels. For this
reason, only the Level 1 is described.
c) Select a Liquid Control option(1) by
pressing it, in this example Level 1.
1 Liquid Controls option
Liquid Controls
L2 123456789
L3 123456789
L4 123456789
DeleteDelete AddAdd
2
1
Liquid Controls
Level 2
Level 3
Level 4
Level 1
1
