10 Zone LED Alarm Panel - Engineering Manual
43
Section 10 - Specifications
10 ZONE ONBOARD LED ALARM PANEL
Type of Alarm Panel
Microprocessor based control unit
Housing ABS
Entry Delay default 45 seconds, programmable
Exit Delay default 45 seconds, programmable
Alarm Zone
10 Zones - Programmable function
Remote Keypad Up to 4 LED Keypads
Tamper -Ve loop
External Bell box output
DC12V, max current : 400mA, adjustable
timer( 1-20 mins)
Strobe output DC12V latching
External Speaker DC12V 16ohm, max current : 220mA
Set+ output
0V in Day mode
13V in Set mode
Siren Duration Default 14 minutes
Current consumption control panel
Standby : 50mA
Alarm : 100mA
Current consumption for LED keypad
Standby : 40mA
Alarm : 70mA
Low voltage output 13.8V DC stabilized(+/- 5%) up to 350mA
Rechargeable battery DC12V, up to 2.1Ah
Charge Voltage 13.8V dc
Board fuse on control panel 1.6A 20mm quick blow
Main input fuse 1.6A 20mm quick blow
Total Current output 1A when supported by a fully charged battery
Mains supply voltage 230V AC (+/- 10%) 50Hz max load 0.5A
Ambient operating temperature
0℃
~ 4
0℃
Dimensions (mm) 253 x 195 x 61
