User Manual of DS-7200/7300/8100 Series DVR
170
Figure 9. 25 External Port Settings Dialog Box
2) Click Apply to save the settings.
3) You can click Refresh to get the latest status of the port mapping.
Figure 9. 26 UPnP™ Settings Finished-Manual
Manual Mapping
If your router does not support the UPnP
TM
function, perform the following steps to map the port manually in
an easy way.
Before you start:
Make sure the router support the configuration of internal port and external port in the interface of
Forwarding.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the NAT tab to enter the port mapping interface.
3. Leave the Enable UPnP checkbox unchecked.
4. Click to activate the External Port Settings dialog box. Configure the external port No. for server
port, http port, RTSP port and https port respectively.
The value of the RTSP port No. should be 554 or between 1024 and 65535, while the value of the other
ports should be between 1 and 65535 and the value must be different from each other. If multiple
devices are configured for the UPnP™ settings under the same router, the value of the port No. for each
device should be unique.
