User Manual of DS-7200/7300/8100 Series DVR
94
5.5 Configuring VCA Record
Purpose:
The face detection VCA event is supported by DS-7200HWI-E1(2)/C/F, and the line crossing detection and
intrusion detection are supported by other smart DVR/HVR models. The VCA triggered recording can be
configured.
The VCA settings and VCA event triggered recording are supported by the analog cameras 01~02 only.
Steps:
1. Enter the VCA settings interface and select a camera for the VCA settings.
Menu> Camera> VCA or Menu> Camera> Face Detection (DS-7200HWI-E1(2)/C/F)
DS-7200HWI-E1(2)/C/F
Other Smart DVR/HDVR
Figure 5. 26 VCA Settings
2. Configure the detection rules for VCA events. For details, see the step 2 in Chapter 8.5 Detecting VCA
Alarm.
3. Click the icon to configure the alarm linkage actions for the VCA events.
Select Trigger Channel tab and select one or more channels which will start to record when VCA alarm
is triggered.
Click Apply to save the settings
