User Manual of DS-7200/7300/8100 Series DVR
67
4.2 Configuring PTZ Settings (B)
This section is applied to the Smart/Coaxitron HDVR and Smart DVR/HDVR series.
Purpose:
Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters should be done
before you control the PTZ camera.
Before you start:
Make sure that the PTZ camera and the device are connected properly via RS-485 interface.
Steps:
1. Enter the PTZ Settings interface.
Menu > Camera > PTZ
Figure 4. 15 PTZ Settings
2. Select the camera for PTZ setting from the drop-down list.
3. Click the RS-485 Settings button and then configure the RS-485 parameters of the device.
4. Enter the parameters of the PTZ camera.
