User Manual of DS-7200/7300/8100 Series DVR
200
11.4 Configuring Video Quality Diagnostics
Purpose:
When the video quality is diagnosed abnormal (e.g., blurred image, abnormal brightness and color cast), the alarm
will be triggered and linked with the configured response actions
The DS-7200HWI-E1(2)/C/F does not support video quality diagnostics.
Steps:
1. Enter the Video Quality Diagnostics interface.
Menu> Camera > Video Quality Diagnostics
2. Select the camera for adjusting the video quality parameters.
3. Check the checkbox to enable the Video Quality Diagnostics.
4. Click the to enter the Settings interface. Configure the arming schedule of triggering video quality
diagnostics alarm.
Figure 11. 6 Arming Schedule of VQD
5. Configure the linkage actions of video quality diagnostics alarm.
Figure 11. 7 Linking Actions of VQD
