User Manual of DS-7200/7300/8100 Series DVR
42
For the 4-ch HDVR, 1 IP camera can be added, and for the 8-ch and 16-ch HDVR, 2 IP cameras
can be added.
Table 2. 1 Explanation of the icons
Edit basic parameters of the camera
Add the detected IP camera.
The camera is disconnected; you can
click the icon to get the exception
information of camera.
Play the live video of the connected
camera.
Advanced settings of the camera.
Upgrade the connected IP camera.
Show the security status of the camera
to be active/inactive or the password
strength (strong/medium/weak/risk)
2.4.3 Configuring the Connected IP Cameras
Purpose:
The detailed information of the added IP cameras will be displayed on a list, and you can configure the basic
setting of the cameras if needed.
Steps:
1. Click the icon on the camera list to enter the Edit IP Camera interface.
Figure 2. 20 Edit IP Camera
2. Edit the camera information, such as the IP address, protocol, port, etc.
3. Click the button OK to save the new settings.
To edit advanced parameters:
1. Drag the horizontal scroll bar to the right side and click the icon.
