HIKVISION DS-7200 Series User Manual

User Manual of DS-7200/7300/8100 Series DVR
89
Figure 5. 17 Record Schedule
The VCA recording type is supported by the Smart DVR/HDVR series only.
1) Check the checkbox after the Enable Schedule item.
2) Click Edit.
Figure 5. 18 Edit Schedule- Motion Detection
3) In the message box, you can choose the day to which you want to set schedule.
4) Set the Type as Motion.
5) To schedule an all-day recording, check the checkbox after the All Day item.
6) To arrange other schedule, leave the All Day checkbox blank and set the Start/End time.
Up to 8 periods can be configured for each day. And the time periods can’t be overlapped each
other.
Repeat the above steps3)-6) to schedule motion detection triggered recording for all the week. If
the schedule can also be set to other days, click Copy.
