Recording is triggered by events.
2.
Select a camera in Camera No.
3.
Turn on Enable.
4.
Congure the recording schedule.
Edit
Schedule
a. Click Edit.
b. Select a day to congure in Weekday.
c. To set an all-day recording schedule, check All Day and select schedule type.
d. To set other schedules, uncheck All Day, and set Start/End Time and
schedule type.
Note
Up to 8 periods can be congured for each day. And the me periods cannot
be overlapped with each other.
e. Click OK to save the sengs and go back to upper level menu.
Draw
Schedule
a. Click to select schedule type as Connuous or Event.
b. On the table, drag the mouse on the desired period to draw a colored bar.
5.
Click Apply.
5.6.3
Congure Recording Parameter
Steps
1.
Go to Conguraon → Record → Parameter .
2.
Congure recording parameters.
Main Stream
Main stream refers to the primary stream that aects data recorded to the hard disk drive
and will directly determine your video quality and image size. Comparing with the sub-
stream, the main stream provides a higher quality video with higher
resoluon and frame
rate.
Sub-Stream
Sub-stream is a second codec that runs alongside the mainstream. It allows you to reduce the
outgoing internet bandwidth without
sacricing your direct recording quality. Sub-stream is
oen exclusively used by smartphone applicaons to view live video. Users with limited
internet speeds may benet most from this seng.
Resoluon
Image resoluon is a measure of how much detail a digital image can hold: the greater the
resoluon, the greater the level of detail. Resoluon can be specied as the number of pixel-
columns (width) by the number of pixel-rows (height), e.g.,1024×768.
Frame Rate
Network Video Recorder User Manual
37
