By NVR
The event will be analyzed by NVR. The device can analyze videos that contain human and
vehicle. Only the target of selected type (human or vehicle) will trigger alarms, which can
reduce false alarms that are caused by other objects.
By Camera
The event will be analyzed by camera.
4.
Turn on Enable.
5.
Oponal: Check Save VCA Picture to save the captured pictures of VCA detecon.
6.
Set the
detecon rules and detecon areas.
1) Set Arming Area. Up to 4 arming areas are selectable.
2) Adjust
Sensivity. Sensivity: Range [0-100]. The higher the value is, the more easily the
detecon alarm can be triggered.
3)
Oponal: Set Detecon Target as Human or Vehicle to discard alarms which are not triggered
by human body or vehicle.
4) Click Max. Size and draw a quadrilateral in the preview window to set the maximum draw
area size.
5) Click Min. Size and draw a quadrilateral in the preview window to set the minimum draw area
size.
6) Click Draw Area and draw a quadrilateral in the preview window by specifying four vertexes of
the
detecon region.
7.
Set the arming schedule. Refer to Congure Arming Schedule for details.
8.
Set the linkage acons. Refer to Congure Alarm Linkage Acon for details.
9.
Click Apply.
Region
Exing Detecon
Region exing detecon funcon detects people, vehicles or other objects which exit from a pre-
dened virtual region, and some certain acons can be taken when the alarm is triggered.
Steps
1.
Go to Conguraon → Event → Smart Event → Region Exing .
2.
Set Camera.
3.
Select VCA Mode.
By NVR
The event will be analyzed by NVR. The device can analyze videos that contain human and
vehicle. Only the target of selected type (human or vehicle) will trigger alarms, which can
reduce false alarms that are caused by other objects.
By Camera
The event will be analyzed by camera.
4.
Turn on Enable.
5.
Oponal: Check Save VCA Picture to save the captured pictures of VCA detecon.
Network Video Recorder User Manual
71
