MAINTENANCE
7-76
7
Check
W
indshield
Washer F
luid Level
--- as required
Check fluid in windshield washer tank (1).
If the fluid level is low
, remove cap (2) and add fluid via the
opening.
During winter season, use all season windshield washer
which will not freeze
.
M1U1-07-085
2
1
M1U1-07-036
2
1
ZX200-3, 270-3 , 330-3 Class
ZX180-3 Class
M1U1-07-110
ZX120-3 Class
2
1
267
269
