Hitachi 120-3 class User Manual

SPECIFICATIONS
12-14
SHOE TYPES AND APPLICATIONS
ZX160LC-3
Shoe Width
500 mm (20”)
Grouser Shoe
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
Application For Ordinary Ground For Weak Footing For Weak Footing For Weak Footing
Operating Weight kg
(lb)
16600
(36600)
16800
(37000)
17100
(37700)
17400
(38400)
Basic Machine Weight kg
(lb)
13100
(28880)
13300
(29300)
13600
(30000)
13900
(30600)
Cab Height mm
(ft•in)
2950
(9’8”)
2950
(9’8”)
2950
(9’8”)
2950
(9’8”)
Minimum Ground mm
Clearance (ft•in)
470
(19”)
470
(19”)
470
(19”)
470
(19”)
Undercarriage mm
Length (ft•in)
3920
(12’10”)
3920
(12’10”)
3920
(12’10”)
3950
(12’10”)
Undercarriage Width mm
(ft•in)
2490
(8’2”)
2590
(8’6”)
2690
(8’9”)
2890
(9’6”)
Ground Pressure
48 kPa
(0.49 kgf/cm
2
,
7.0 psi)
40 kPa
(0.41 kgf/cm
2
,
5.8 psi)
35 kPa
(0.36 kgf/cm
2
,
5.1 psi)
31 kPa
(0.32 kgf/cm
2
,
4.5 psi)
NOTE: • The specifications for the front-end attachment is for 2.58 m (8 ft 6 in) arm with PCSA 0.6 m
3
(0.79 yd
3
) bucket.
• 700, 800 mm (28, 31 in) and 900 mm (35 in) grouser shoe should not be used on gravel or rocky ground.
• The dimensions do not include the height of the shoe lug.

Hitachi 120-3 class Specifications

General

Brand	Hitachi
Model	120-3 class
Category	Excavators
Language	English
