Hitachi 120-3 class User Manual

OPTIONAL ATTACHMENTS AND DEVICES
13-36
SHOE TYPES AND APPLICATIONS
ZX210LCN-3 2-piece Boom
Shoe Width
500 mm (20”)
Grouser Shoe
600 mm (24”)
Grouser Shoe
Application
For Ordinary
Ground
For Weak Footing
Operating Weight kg
(lb)
21700
(47800)
21900
(48300)
Base Machine Weight kg
(lb)
16700
(36800)
16800
(37000)
Cab Height mm
(ft•in)
2950
(9’8”)
2950
(9’8”)
Minimum Ground mm
Clearance (ft•in)
✹
450
(18”)
✹
450
(18”)
Undercarriage mm
Length (ft•in)
4460
(14’8”)
4460
(14’8”)
Undercarriage Width mm
(ft•in)
2480
(8’2”)
2580
(8’6”)
Ground Pressure
54 kPa
(0.55 kgf/cm
2
,
7.8 psi)
45 kPa
(0.46 kgf/cm
2
,
6.5 psi)
ZX240N-3 2-piece Boom
Shoe Width
550 mm (22”)
Grouser Shoe
Application
For Ordinary
Ground
Operating Weight kg
(lb)
23200
(51100)
Base Machine Weight kg
(lb)
18200
(40100)
Cab Height mm
(ft•in)
2950
(9’8”)
Minimum Ground mm
Clearance (ft•in)
✹
450
(18”)
Undercarriage mm
Length (ft•in)
4200
(14’0”)
Undercarriage Width mm
(ft•in)
2480
(8’2”)
Ground Pressure
55 kPa
(0.56 kgf/cm
2
,
8.0 psi)
NOTE: • The specifications for the front-end attachment is for 2.91 m (9 ft 7 in) arm with PCSA 0.8 m
3
(1.05 yd
3
) bucket.
• 600 mm (24 in) and 700 mm (28 in) grouser shoe should not be used on gravel or rocky ground.
•
✹
The dimensions do not include the height of the shoe lug.
