SPECIFICATIONS
12-35
SHOE TYPES AND APPLICATIONS
ZX280LC-3
Shoe Width
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
600 mm (24”)
Flat Shoe
Application For Ordinary Ground For Weak Footing For Weak Footing For Paved Road
Operating Weight kg
(lb)
28200
(62200)
28800
(63500)
29100
(64200)
29100
(64200)
Basic Machine Weight kg
(lb)
22000
(48500)
22600
(49800)
22900
(50500)
22900
(50500)
Cab Height mm
(ft•in)
3100
(10’2”)
3100
(10’2”)
3100
(10’2”)
3260
(10’8”)
Minimum Ground mm
Clearance (ft•in)
510
(20”)
510
(20”)
510
(20”)
550
(22”)
Undercarriage mm
Length (ft•in)
4940
(16’2”)
4940
(16’2”)
4940
(16’2”)
4940
(16’2”)
Undercarriage Width mm
(ft•in)
3190
(10’6”)
3290
(10’10”)
3390
(11’1”)
3190
(10’6”)
Ground Pressure
53 kPa
(0.54 kgf/cm
2
,
7.7 psi)
46 kPa
(0.47 kgf/cm
2
,
6.7 psi)
41 kPa
(0.42 kgf/cm
2
,
6.0 psi)
55 kPa
(0.56 kgf/cm
2
,
8.0 psi)
ZX280LCN-3
Shoe Width
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
600 mm (24”)
Flat Shoe
Application For Ordinary Ground For Weak Footing For Weak Footing For Paved Road
Operating Weight kg
(lb)
28000
(61700)
28600
(63100)
29000
(63900)
29000
(63900)
Basic Machine Weight kg
(lb)
21800
(48100)
22400
(49400)
22800
(50300)
22800
(50300)
Cab Height mm
(ft•in)
3100
(10’2”)
3100
(10’2”)
3100
(10’2”)
3260
(10’8”)
Minimum Ground mm
Clearance (ft•in)
510
(20”)
510
(20”)
510
(20”)
550
(22”)
Undercarriage mm
Length (ft•in)
4940
(16’2”)
4940
(16’2”)
4940
(16’2”)
4940
(16’2”)
Undercarriage Width mm
(ft•in)
3000
(9’10”)
3100
(10’2”)
3200
(10’6”)
3000
(9’10”)
Ground Pressure
52 kPa
(0.53 kgf/cm
2
,
7.5 psi)
46 kPa
(0.47 kgf/cm
2
,
6.7 psi)
41 kPa
(0.42 kgf/cm
2
,
6.0 psi)
54 kPa
(0.55 kgf/cm
2
,
7.8 psi)
NOTE: • The specifications for the front-end attachment is for 3.11 m (10 ft 2 in) arm with PCSA 1.1 m
3
(1.44 yd
3
) bucket.
• 700, 800 mm (28, 31 in) grouser shoe and 600 mm (24 in) flat shoe should not be used on gravel or rocky ground.
• The dimensions do not include the height of the shoe lug.
