SPECIFICATIONS
12-36
BUCKET TYPES AND APPLICATIONS
ZX280LC-3, 280LCN-3
Bucket
Bucket Capacity
m
3
(yd
3
)
Bucket Width (in)
(With side cutter)
Application Front-End Attachment
PCSA
(Heaped)
CECE
(Heaped)
ZX280LC-3, 280LCN-3
2.42 m
(7’10”)
Arm
3.11 m
(10’2”)
Arm
3.76 m
(12’4”)
Arm
Hoe Bucket
1.00 (1.31)
1.10 (1.44)
1.39 (1.82)
1.62 (2.12)
0.90
1.00
1.20
1.40
1290 (51”)
1340 (53”)
1560 (61”)
1640 (65”)
(With side cutter)
—
Hoe Bucket reinforcement
can be welded in four places
upon customer’s request
1.10 (1.31) 0.90 1340 (53”)
1.39 (1.82) 1.20 1560 (61”)
Rock Bucket 0.92 (1.20) 0.80 1210 (48”)
Ripper Bucket
0.80
(1.05)
1000 (39.4”)
(With side cutter)
—
One Point Ripper — — —
Clamshell Bucket
0.80
(1.05)
Bucket width
975 (38”)
Side
ditching
—
NOTE: • Symbols in the above table have the following meanings.
: General excavating
: Light duty excavating
: Rock digging
: Loading work
—: Not applicable (not warrantable)
• Hoe bucket is applicable to the following types of work.
General excavating:
For digging and loading operation of sand, gravel, clay, ordinary earth and so on.
Light duty excavating:
For digging and loading operation of dry, loosened earth, sand, mud and so on.
Their bulk density shall be less than 1.60 t/m
3
(2700 lb/yd
3
) as a standard.
Loading:
For loading operation of dry, loosened earth and sand.
Their bulk density shall be less than 1.10 t/m
3
(1850 lb/yd
3
) as a standard.
Rock digging:
For digging/loading operation of mountain gravels, blasted rock, hard clay, soft rock and so on.
IMPORTANT: Using inapplicable buckets may cause serious damage to the front structure such as boom, arm and
hydraulic cylinders.
