OPTIONAL ATTACHMENTS AND DEVICES
13-8
AVOID HITTING BLADE WITH FRONT-END AT-
TACHMENT
When operating the machine with the blade positioned to-
wards the front, the bucket or boom cylinder may come into
contact with the blade if you are not careful. Be sure to prevent
this from happening.
AVOID HITTING BLADE WITH BUCKET
When crowding the arm into a traveling or transporting posi-
tion, be careful not to let the bucket hit the blade.
AVOID STRIKING THE BLADE INTO A ROCK
Do not attempt to strike large rocks with the blade, as doing
so will damage the blade and the blade cylinders, shortening
their operating lives.
WRONG
WRONG
WRONG
M155-14-009
M155-14-010
WRONG
M155-14-010
M155-14-011
