Hitron CODA-551x User’s Guide
4.4 The Basic: Port Forwarding Screen
Use this screen to configure port forwarding between computers on the WAN and
computers on the LAN. You can turn port forwarding on or off and configure new and
existing port forwarding rules.
Click Basic > Port Forwarding. The following screen displays.
Figure 23: The Basic: Port Forwarding Screen
The following table describes the labels in this screen.
Table 15: The Basic: Port Forwarding Screen
All Port Forwarding
Rules
Use this field to turn port forwarding on or off.
Select Enabled to turn port forwarding on.
Select Disabled to turn port forwarding off.
Port Forwarding Rules
Application Name This displays the arbitrary name you assigned to the
rule when you created it.
Public These fields display the ports to which the rule applies:
The Public field displays the incoming port range.
These are the ports on which the CODA-551x
received traffic from the originating host on the WAN.
The Private field displays the port range to which the
CODA-551x forwards traffic to the device on the
LAN.
Private
