Honda CBR1000RR 2006 User Manual

(2)
(1)
(1) front seat
(2) mounting bolts
(3) collars
(4) tabs
(3)
(4)
92
Seat Removal
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Front Seat Removal
The front seat must be removed for
battery or fuse maintenance.
To remove the front seat ( ), pull the rear
corners of the seat back, remove the two
mounting bolts ( ) and collars ( ), and
then pull the seat up and back.
To install the front seat, insert the tabs ( )
into the recess under the frame and tighten
the mounting bolts securely.
1
3
76
2
4
05/11/25 12:25:09 31MEL620_101

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
