Honda CBR1000RR 2006 User Manual

(1)
RIGHT HANDLEBAR
(2)
OFF
RUN
(1) start button
(2) engine stop switch
40
Start Button Engine Stop Switch
Controls & Features
Instruments & Controls
Starting Procedure,
When the start button is pushed, the starter
motor will crank the engine; the headlight
will automatically go out, but the taillight
will stay on.
The start button ( ) is used for starting the
engine. Pushing the button in starts the
engine. See page .
The engine stop switch ( ) is used to stop
the engine in an emergency. To operate,
push the switch to the OFF position. The
switch must be in the RUN position to
start the engine, and it should normally
remain in the RUN position even when the
engine is OFF.
The engine will not operate if the engine
stop switch is in the OFF position when
the start button is pushed.
1
2
58
05/11/25 12:18:14 31MEL620_049

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
