Honda CBR1000RR 2006 User Manual

(2)
(1)
(1) adjuster dial
(2) brake lever
(3) index mark
(4) numbers
(3)
(4)
RIGHT HANDLEBAR
131
Front Brake Lever Adjustment
Brakes
Servicing Your Honda
Saf ety Precautions
The hydraulic braking systems on your
motorcycle dissipate the heat generated by
the friction of the brake pads on the brake
discs as the wheels are slowed.
As the brake pads wear, the brake fluid
level will drop. A leak in the system will
also cause the level to drop.
Frequently inspect the system to ensure
there are no fluid leaks. Periodically
inspect the brake fluid level and the brake
pads for wear.
If the brake lever or brake pedal freeplay
does not feel within the normal range
while riding, check the brake pads for
wear (page ). Worn pads should be
replaced. If the pads are not worn beyond
the recommended limit, there is probably
air in the brake system. See your Honda
dealer to have the air bled from the system.
Refer to on page .
The distance between the tip of the brake
lever and the grip may be adjusted.
135
76
05/11/25 12:31:04 31MEL620_140

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
