Honda CBR1000RR 2006 User Manual

(1) RESET button
(2) SEL button
(1)(2)
35
Changing the Temperature Unit
Gauges, Indicators & Displays
Instruments & Controls
This function can be operated after the
speed and mileage unit change mode
(page ).
As you turn off the ignition switch during
the presetting procedures, the preset data
just before turning off the ignition switch
will be registered.
The display will stop flashing
automatically if the button is not pressed
for about 30 seconds.
The coolant temperature meter displays
both ‘‘°F’’ (Fahrenheit) and ‘‘°C’’
(Centigrade).
Push the RESET button ( ) to select
‘‘°F’’ or ‘‘°C’’.
To end the selection, push the SEL button
().
(USA only)
1
34
2
05/11/25 12:17:24 31MEL620_044

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
