Honda CBR1000RR 2006 User Manual

(1)
(2)
(1) clips A
(2) clips B
(3) inner lower cowl
(3)
95
Servicing Your Honda
Inner Lower Cowl Removal
Saf ety PrecautionsRefer to on page .
Removal
The inner lower cowl must be removed to
remove the under cowl.
Remove the clips A ( ) and clips B ( ).
Remove the inner lower cowl ( ).
Installation can be done in the reverse
order of removal.
Installation
76
1.
2.
12
3
05/11/25 12:25:39 31MEL620_104

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
