Honda CBR1000RR 2006 User Manual

LEFT HANDLEBAR
(1)
(2)
(3)
(1) adjuster dial
(2) clutch lever
(3) index mark
(4) numbers
(4)
117
Clutch Lever Adjustment
Clutch System
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Your motorcycle has a hydraulically-
actuated clutch. There are no adjustments
to perform, but the clutch system must be
inspected periodically for fluid level and
leakage.
The distance between the tip of the clutch
lever and the grip may be adjusted.If the motorcycle creeps or stalls when
shifted into gear, or if the clutch slips,
causing acceleration to lag behind engine
speed, there is probably air in the clutch
system. See your Honda dealer to have the
air bled out of the system.
76
05/11/25 12:28:54 31MEL620_126

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
