Honda CBR1000RR 2006 User Manual

122
Suspension
Servicing Your Honda
Your front and rear suspension systems
use springs, hydraulic damping devices,
and linkages (rear only) that suspend your
weight and most of the weight of your
motorcycle.
The spring pre-loads for your front and
rear suspension systems adjust the amount
of force required to begin compression of
the spring.
Consider adjusting your suspension
whenever you change your normal load,
by adding or subtracting a passenger,
cargo, or accessories, or when the road or
riding conditions change.
The oil damper systems hydraulically
control the natural compression and
rebound of the suspension springs so that
traction and comfort are maintained as the
wheels ride over road surfaces.
The way you ride your motorcycle and the
type of ride you want to experience can
also influence your suspension needs.
You may adjust the spring pre-load and
the rebound and compression damping of
both suspension systems.
05/11/25 12:29:32 31MEL620_131

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
