Honda CBR1000RR 2006 User Manual

−
42
Horn Button
RESET Button
Controls & Features
Instruments & Controls
The horn is used to alert other motorists.
To operate, push the horn button ( ).
Resets the tripmeter to zero (0) (page ).
Also used to change the temperature unit
for the coolant temperature meter (page
). (USA only)
Also used to change the speed and mileage
unit for the speedometer/odometer/
tripmeter (page ).
Also used to change the shift indicator and
its display (pages ).
Also used to display the total mileage of
the odometer when you drive 100,000
miles (kilometers) or more (page ).
Also used to set the digital clock (page
).
3
31
34
35
36 38
30
32
05/11/25 12:18:32 31MEL620_051

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
