Honda CBR1000RR 2006 User Manual

(2)
(1)
(1) low oil pressure indicator
(2) malfunction indicator lamp (MIL)
26
Gauges, Indicators & Displays
Instruments & Controls
Low Oil Pressure Indicator and
Malfunction Indicator Lamp (MIL)
The low oil pressure indicator ( ) and the
malfunction indicator lamp (MIL) ( )
light when engine oil pressure is low
enough to cause engine damage.
The low oil pressure indicator and the
malfunction indicator lamp (MIL) should
also light when the ignition switch is
turned ON. The malfunction indicator
lamp (MIL) and the low oil pressure
indicator stay on until after the engine is
started.
If the low oil pressure indicator and the
malfunction indicator lamp (MIL) light,
pull safely to the side of the road.
See page for instructions and cautions.
1
193
2
05/11/25 12:16:10 31MEL620_035

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
